ADT 6270ADT User Manual

2–1
SECTION 2
Mounting and Wiring
xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
In This Section
♦
Mounting the 6270ADT
♦
Wiring the 6270ADT
xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
Mounting the 6270ADT
The 6270ADT should be mounted using the following criteria:
x
The 6270ADT must be mounted indoors, and
x
should be mounted at eye level for easy viewing by the user.
To mount the 6270ADT, see Figure 1 and complete the following
steps:
1. Detach the case back by pushing up into the two tabs located at
the bottom of the 6270ADT with the blade of a screwdriver while
pulling the case back and case front apart.
2. Locate the case back over the mounting surface such that the
opening in the case back is aligned with the wire/cable access
opening (in the mounting surface) while passing the wires/cable
through the opening in the case back.
3. Secure the case back to the mounting surface using four screws
(supplied).
Prior to attaching the case front to the case back, be sure to wire the
6270ADT as described in the "
Wiring the 6270ADT
" paragraph in this
section.
