6270ADT Installation and Setup Guide
4–2
6270ADT Initialization
Power Up
When initially powered, the screen displays the boot sequence as it is
performed. After it is determined what services are available, the
screen displays the Set ECP Address screen.
SCREEN ACTION
If the system is incorporating only one
6270ADT, leave the address set to 1 and
press the
OK
button. The boot-up
process will continue until completion.
If there are to be additional 6270ADT units
in the system, refer to the
How to Change
the ECP Address
paragraph.
How to Change the ECP Address
After enabling addresses in the control panel using an alpha-keypad,
power up each 6270ADT one at a time, and set its address to one of
the addresses you enabled in the control panel. If this is a first time
power-up of the unit, follow the initialization procedure in this
section. Otherwise, access the Central Station screen then follow the
procedure to change the address on the unit.
To Next Page
