Operation Display Patterns
13
Document 50520 Rev D 7/25/00 P/N 50520:D
Section 2:
Operation
2.1 Display Patterns
The ADT-LCD40 Series Annunciators directly display (mimic) the
information on the Unimode 200 main circuit board LCD display with
the following exceptions:
• Upon Power-up, the ADT-LCD40 Series may display the
following message until a valid message is received from the
Unimode 200
• If an ADT-LCD40 Series Annunciator fails to receive communi-
cations from the panel for a period of over 30 seconds, it will
activate its local sounder (if so programmed) and display the
following message:
• When placing the host Unimode 200 into some aspects of the
Programming Mode, the annunciator will display the following
message:
The message shown above will appear at the Level One passcode for
(1) Autoprogram, (2) Point Edit, (3) System Edit, (4) Passcode Entry
and (5) Load. The same message will also appear at the Level Two
passcode for (1) Disable, (2) Clear History and (4) Time.
SYSTEM POWER UP
WAITING FOR THE FACP
COMMUNICATIONS FAIL
PROGRAMMING THE
UNIMODE-200 PANEL
