Mounting Hardware and Backboxes

Document 50520 Rev D 7/25/00 P/N 50520:D

Ack Silence

Reset

Drill

Ho ld 2 sec.

FIRE ALARM ANNUNCIATOR

Figure 3-2: Hardware and Backboxes

ADT-LCD40 Series flange

ADT-LCD40 Series Trim Ring

(replacement P/N 23165)

3-Gang Electrical Box P/N 10103

(semi-flush mount)

3-Gang Electrical Box P/N SBB-3

(surface mount)
