NetVanta 4660/5660 Series Appendix A
617004660F1-34A Copyright © 2014 ADTRAN, Inc. 37
Network Module Pinouts
Table A-5. Quad SHDSL EFM Pinouts
Ports 1 and 2 Ports 3 and 4
Pin Name Description Pin Name Description
1 T02 Loop 2 - Tip 1 T04 Loop 4 - Tip
2 R02 Loop 2 - Ring 2 R04 Loop 4 - Ring
3 — Unused 3 — Unused
4 T01 Loop 1 - Tip 4 T03 Loop 3 - Tip
5 R01 Loop 1 - Ring 5 R03 Loop 3 - Ring
6-8 — Unused 6-8 — Unused
Table A-6. Octal SHDSL EFM (Ports 1 through 4) Pinouts
Ports 1 and 2 Ports 3 and 4
Pin Name Description Pin Name Description
1 T02 Loop 2 - Tip 1 T04 Loop 4 - Tip
2 R02 Loop 2 - Ring 2 R04 Loop 4 - Ring
3 — Unused 3 — Unused
4 T01 Loop 1 - Tip 4 T03 Loop 3 - Tip
5 R01 Loop 1 - Ring 5 R03 Loop 3 - Ring
6-8 — Unused 6-8 — Unused
Table A-7. Octal SHDSL EFM (Ports 5 through 8) Pinouts
Ports 5 and 6 Ports 7 and 8
Pin Name Description Pin Name Description
1 T06 Loop 6 - Tip 1 T08 Loop 8 - Tip
2 R06 Loop 6 - Ring 2 R08 Loop 8 - Ring
3 — Unused 3 — Unused
4 T05 Loop 5 - Tip 4 T07 Loop 7 - Tip
5 R05 Loop 5 - Ring 5 R07 Loop 7 - Ring
6-8 — Unused 6-8 — Unused
