Advanced Diagnostics TCODE PRO - Type 4 Key and Remote Programming

551
Advanced Diagnostics USA Manual for MVP & TCODE PRO – Copyright 2014 Advanced Diagnostics USA INC.
(Use this method if you have at least 1 Master Key.)
PROGRAM KEYS - TYPE 4
VEHICLE SELECTION
MITSUBISHI
NISSAN
SUZUKI
> TOYOTA
V.W./AUDI GROUP
VEHICLE SELECTION
> Immobilizer
REMOTE
PROXIMITY
ECU IDENTIFICATION
TOYOTA/LEXUS TYPE X
PRESS ENTER KEY
SWITCH IGNITION ON
PRESS ENTER KEY
DIAGNOSTIC MENU
ECU IDENTIFICATION
FAULT CODES
LIVE DATA
ACTUATORS
> SPECIAL FUNCTIONS
DIAGNOSTIC MENU
RESET Immobilizer
> PROGRAM KEY
ERASE KEYS
RESET ECU
PROGRAM KEY
SWITCH IGNITION OFF
REMOVE KEY
INSERT KEY
SWITCH IGNITION ON
WITHIN 120 Sec
TIME ELAPSED: 0 S
PRESS ENTER KEY
PROGRAM KEY
SWITCH IGNITION OFF
REMOVE KEY
WITHIN 20 Sec
TIME ELAPSED: 0 S
PRESS ENTER KEY
NOTE: If you do not have an existing Master key you must use the “Reset Immobilizer” procedure to Reset
the Immobilizer system. A Valet key will not work as a substitute for a Master Key.
Note: You must remove the
Master key & then press
enter.
PROGRAM KEY
INSERT NEW KEY
LEAVE IGNITION OFF
WITHIN 10 Sec
TIME ELAPSED: 0 S
PRESS ENTER KEY
PROGRAM KEY
PLEASE WAIT
TIME ELAPSED: 2 S
PROGRAM KEY
PROCEDURE COMPLETE
TIME ELAPSED: 59 S
PRESS ENTER KEY
Note: This usually takes about 60 seconds.
If the timer goes past 120 seconds, stop.
The key is most likely now programmed.
Disconnect & try key.
Note: You must insert the New key,
but Do Not turn it.
Press Enter when done.
VEHICLE SELECTION
TYPE 1
TYPE 2
TYPE 3
> TYPE 4
MVP &
TCODE
TOYOTA
ADVANCED DIAGNOSTICS USA
powered
by
