5 AV-VBM and AV-VB Battery Calculations
Quiescent Load Alarm Load
Equipment I (A) x Total I (A) x Total
AV-AMP-80 0.035 1.0 = 0.035 0.220 1.0 = 0.220
AV-ZS (optional) 1.0 0.075 1.0
Amplifier 1
1
1.0 =
Amplifier 2
1
1.0 =
Total
Quiescent Load
=
Alarm Load
=
x 24 hr or 60 hr
Ah
x 0.0833
2
hr
Total Quiescent Current
Ah
Total Alarm Current
Ah
Total Load (Quiescent + Alarm)
Ah
Total Load x 1.20 (battery de-rating factor) Ah
Converting Watts to Amps:
Utilizing Ohm’s Law (Amps = Watts / Volts), convert amplifier wattage to amperes.
i.e.: maximum load per amplifier 40 Watts
Amps = 40w / 25vrms
Amps = 1.6
1
Add total speaker circuit load of each amplifier, 40 watts maximum per amplifier.
2
5 minutes in alarm, change to .166 for 10 minutes in alarm.
