www.advancedco.com
www.advancedco.com
9
OUT- OUT+ IN- IN+
AMP1
OUT-OUT+ IN- IN+
AMP2
+24V GND +24V GND
POWER
B A B A
RS485
AMP-1
A+ A- B- B+
AMP-2
A+ A- B- B+
INPUTS
IN1 GND IN2 GND IN3 GND
TROUBLE
COM NO NC
Figure 3 – AV-VBM and AV-VB Module Removal
AV-MIC
6-way Ribbon Cable
(AV-VBM Only)
Mounting Plate Screws
Mounting Plate Screws
Mounting Plate Screw
