C. A free air space of at least four (4) feet is required at the condenser intake and six (6) feet
atthecondenserdischargetoallowforproperairow.
D. At full load, the chiller will discharge approximately
15,000BTU’sperhourpertonofcooling.
E. On centrifugal blower units, air discharge duct work
shouldbesizedbyaqualiedHVACengineer.
Sizing shall be according to rated CFM at the static
pressureof.90inchesofwater.Seegureatright.
F. All air cooled units MUST have all enclosure panels
in place before operating the compressor. Air will
not be drawn through the condenser coil if the
panels are not in place. Starting the unit without the
enclosure panels in place will result in a refrigerant fault.
G. Condenser Air Filtering.Usealterthatproducesverylowairowrestrictions.
GenerallyadisposableberglasslterwithaMERVratingof2-3providesadequateair
ltration.Thepurposeofthelteristopreventlargeparticlessuchasdust,lintanddebris
fromfoulingthecondenser.Youshouldbeabletoseethroughtheltermedia.Using
restrictiveltermediacancauselossofchillercapacity,difcultyrunninginwarmweather
and fan motor overheating.
CFM RATINGS
Model
5 Tons
7.5 Tons
10 Tons
15 Tons
20 Tons
25 Tons
30 Tons
CFM
5,000
7,500
10,000
15,000
20,000
25,000
30,000
WARNING: Do not attempt to duct exhaust air from a portable chiller using motor driven fans.
Exhaust air can only be ducted from a portable chiller using a centrifugal blower assembly.
Typical Filter materials.
Typical Filter shown on 10 ton air-cooled unit.
WARNING: Do not attempt to start or operate an air-cooled portable chiller without all cabinetry
panels in place. Air-cooled chillers require air to be drawn through the air-cooled condenser. This
will not occur if the panels are not in place.
