Advantage Maximum MG Series - Table of Contents

Maximum Series Portable Chiller : Air & Water-Cooled : MG Series Instrument
update 08/02/2021
Page: 4
ADVANTAGE ENGINEERING, INC.
525 East Stop 18 Road Greenwood, Indiana 46142
317-887-0729 Fax: 317-881-1277
Service Department Fax: 317-885-8683
Email: service@AdvantageEngineering.com
TABLE OF CONTENTS
1.0 GENERAL 7
1.1 Introduction 8
1.2 Safety 8
1.3 Receiving instructions 9
 1.4 Efciency 9
1.5 Clean air act 9
1.6 Water Treatment 10
1.7 Components 10
2.0 INSTALLATION 13
2.1 General 14
2.2 To and From process connections 14
2.3 Water supply connection 15
2.4 Water make-up supply connection 16
2.5 Air-cooled condenser 16
2.6 Water-cooled condenser 18
2.7 Electrical connection 18
3.0 OPERATIONS 21
3.1 General 22
3.2 Start up/operations procedure 22
3.3 Instrument : Start Up & Operation 30
3.4 Instrument : Main Menu 33
3.5 Instrument : Setpoints Menu 34
3.6 Instrument : Utilities Menu 36
3.7 Instrument : Network Menu 37
3.8 Instrument : Flow Menu (optional) 38
3.9 Instrument : Options Menu 39
3.10 Instrument : Machine Menu 40
3.11 Low Tank Level 42
3.12 Shut down procedure 43
4.0 TROUBLESHOOTING 45
4.1 Unit Will Not Start 46
4.2 Compressor Hums But Will Not Start 46
4.3 Shuts Off On High Pressure 46
4.4 Shuts Off On Low Pressure 47
4.5 Compressor Shuts Off On Internal Overload 48
4.6 Low Or No Process Pressure Or Water Flow 48
4.7 Cooling Capacity Inadequate 49
4.8 Sensor 49
4.9 Coolant Pump 49
4.10 Chiller Controller 49
 4.11 ReplacementInstrumentConguration 51
