update 08/02/2021
Maximum Series Portable Chiller : Air & Water-Cooled : MG Series Instrument
Page: 81
ADVANTAGE ENGINEERING, INC.
525 East Stop 18 Road Greenwood, Indiana 46142
317-887-0729 Fax: 317-881-1277
Service Department Fax: 317-885-8683
Email: service@AdvantageEngineering.com
8.5 STANDARD MG INSTRUMENT SETTINGS
A. Caution:Seesection8.1forpropersettingsbasedonyouruidsetpointtemperature.
Adjustable Low Pressure Cut Out Range
• 9 PSI to 150 PSI
Adjustable Low Pressure Cut In Range
• 19 PSI to 150 PSI
Adjustable High Pressure Cut Out Range
• 225 PSI to 580 PSI
