8.10 REMOTE AND AUTO START FEATURE CONFIGURATION
A. The MG Series control instrument is designed to require a manual restart should an
interruption in power occur.
B. The On/off button is a momentary switch. Some users require that the unit must start
automatically after an interruption in power or must be started from a remote, customer
suppliedon/offsignal.TheMGSeriescontrolinstrumentcanbeconguredinthis
mannerbyfollowingtheinstructionsbelow.Theunitmaybeconguredthiswaybythe
factoryiftheunitisorderedwiththisoptionoritcanbeconguredintheeld.
C. Factory installed remote or auto start feature:
1. IfMGSeriescontrolinstrumenthasbeenfactoryconguredwiththeremoteor
auto start feature the standard on/off buttons will no longer function. A separate
on/off switch has been added to the unit.
2. Use this switch to turn the unit on and off. When in the on position, any time
power is applied the unit will start. Models with compressors that include a
compressor control module (generally 15 horsepower and larger) also include a
factory installed time delay relay of 20 seconds or longer to avoid a compressor
module fault on start-up.
D. Field installed remote or auto start feature:
1. The factory recommends a manual on/off operator be added to the unit for local
control.
2. Install operator and wire to terminals on back of controller (see picture).
3. Note: operator should be on the on position to utilize remote start/stop. Models
with compressors that include a compressor control module (generally 15
horsepower and larger) also require the addition of time delay relay of 20
seconds or longer to avoid a compressor module fault on start-up.
E. To active the Remote Start features :
1. Access main menu and advance to the Options menu.
2. From the Options menu, select Remote Start.
3. Press the Select button to advantage to the Enabled/Disable screen.
4. Select Enabled to enable the Remote Start.
5. Press the Select button to acknowledge and save the selection.
