7.0 RELATED DRAWINGS
7.1 Mechanical Schematic : Water-Cooled : 5 - 10 tons
7.2 Mechanical Schematic : Water-Cooled : 15 - 40 tons
7.3 Mechanical Schematic : Air-Cooled : 5 - 10 tons with Propeller Fans
7.4 Mechanical Schematic : Air-Cooled : 15 - 30 tons and 5 - 20 ton Models with
Optional Centrifugal Blower
7.5 Electrical Drawing : Air-Cooled
7.6 Electrical Drawing : Water-Cooled
7.7 Physical Drawing : Water-Cooled : 5 - 10 Ton
7.8 Duct Schematic for Air-cooled Chillers
