Page: 20
ADVANTAGE ENGINEERING, INC.
525 East Stop 18 Road Greenwood, Indiana 46142
317-887-0729 Fax: 317-881-1277
Service Department Fax: 317-885-8683
Email: service@AdvantageEngineering.com
Typical electrical panel.
Terminal Strip
Pump Starter and
Overload Block
Power Entry Terminal Block
Pump & Transformer Fusing
Transformer: Line Voltage
to 115 volts
Grounding Bus Bar
Compressor & Fan Contactor
Electrical CabinetElectrical Cabinet
WARNING: Check that all owner and factory electrical connections are tight before starting.
Disconnect power before servicing. Follow all facility lock-out tag-out procedures.
