a. Use the Up and Down Arrow buttons to select the correct Chiller Type.
Seethechartbelowforavailablechillercongurations.
b. Use the Right Arrow button to make the selection. A Change Setting
Chiller Type screen will appear.
c. Use the Left or Right Arrow buttons to acknowledge the selection and
return to the Home Screen.
7. Onceconguredcorrectlytheunitisreadytooperate.
Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
MG Display
1C + 1HG [CENT]
1C + 1HG [PORT]
1C + 1UL + 1HG [CENT]
1C + 2UL + 1HG [CENT]
1C + 1UL [CENT]
1C + 2UL [CENT]
2C + 1HG [CENT]
2C + 1HG [PORT]
Screw + 3L [CENT]
Screw + 2L [CENT]
1DIG [CENT]
1DIG [PORT]
1DIG + 1C [CENT]
1DIG + 1C [ PORT]
Chiller Type OUtput Summary
1 Compressor, 1 Hot Gas Bypass
1 Compressor, 1 Hot Gas Bypass
1 Compressor, 1 Unloader, 1 Hot Gas Bypass
1 Compressor, 2 Unloaders, 1 Hot Gas Bypass
1 Compressor, 1 Unloader
1 Compressor, 2 Unloaders
2 Compressors, 1 Hot Gas Bypass
2 Compressors, 1 Hot Gas Bypass
1 Screw Compressor w/ Pulse
1 Screw Compressor w/o Pulse
1 Digital Scroll
1 DIgital Scroll
1 Digital Scroll Compressor, 1 Compressor
1 Digital Scroll Compressor, 1 Compressor
Chiller Type
Central
Portable
Central
Central
Central
Central
Central
Portable
Central
Central
Central
Portable
Central
Portable
Output 1
Compressor
Compressor
Compressor
Compressor
Compressor
Compressor
Compressor
Compressor
Compressor
Screw Compressor
Digital Scroll Compressor
Digital Scroll Compressor
Digital Scroll Compressor
Digital Scroll Compressor
Output 2
XXX
XXX
Unloader
Unloader
Unloader
Unloader
Compressor
Compressor
50% Capacity
50% Capacity
XXX
XXX
Compressor
Compressor
Output 3
XXX
XXX
XXX
Unloader
XXX
Unloader
XXX
XXX
75% Capacity
75% Capacity
XXX
XXX
XXX
XXX
Output 4
Hot Gas Bypass
Hot Gas Bypass
Hot Gas Bypass
Hot Gas Bypass
XXX
XXX
Hot Gas Bypass
Hot Gas Bypass
Pulse
XXX
XXX
XXX
XXX
XXX
MG Chiller - Chiller Type Configuration
