Coil and solenoid base sub assembly
Body
Gasket
Valve body
Core
assembly
Core spring
Diaphragm
spring
Diaphragm assembly
f. Note the arrangement of the
core spring and core assembly,
diaphragm spring and diaphragm
assembly. (See diagram.)
g. Clean all components as required.
