4-152 ADAM 4000 Series User's Manual
Command Set
4050, 4052, 4053, 4060, 4051, 4055, 4068
76543210
%AANNTTCCFF
Name Configuration
Description Configure address, baud rate and/or checksum status of the
addressed digital I/O module.
Syntax %AANNTTCCFF(cr)
% is a delimiter character.
AA (range 00-FF) represents the 2-character hexadecimal
address of the digital I/O module to be configured.
NN represents the new hexadecimal address of the digital I/O
module. Range is from 00h to FFh.
TT represents the type code which is always set to 40 for a
digital I/O module. (ADAM-4050, 4052, 4053, 4060, 4068)
CC represents the baud rate code.
(See next page,
Table 4-5)
FF is a hexadecimal number that equals the 8-bit parameter that
represents the checksum status. (See Figure 4-3).
Bits 0 through
5 and bit 7 are not used and set to 0.
(cr) is the terminating character, carriage return (0Dh).
Checksum status
0: Disabled
1: Enabled
not used
(000000)
not used (0)
Figure 4-3
Checksum Parameter
