Advantech Adam-4018 User Manual

B-8 ADAM 4000 Series User's Manual
Data Formats and I/O Ranges
B.2 Analog Input Ranges
Range
Code
(hex)
Input
Range
Description
Data Formats +F.S. Zero -F.S.
Displayed
Resolution
00 – 15 mV
Engineering
Unite
+15.000 –00.000 -15.000 1 v
%ofFSR +100.00 –000.00 -100.00 0.01%
Two s
Complement
7FFF 0000 8000 1 LSB
1
01 – 50 mV
Engineering
Unite
+50.000 –00.000 -50.000 1 v
%ofFSR +100.00 –000.00 -100.00 0.01%
Two s
Complement
7FFF 0000 8000 1 LSB
1
02 – 100 mV
Engineering
Unite
+100.00 –000.00 -100.00 10 v
%ofFSR +100.00 –000.00 -100.00 0.01%
Two s
Complement
7FFF 0000 8000 1 LSB
1
03 – 500 mV
Engineering
Unite
+500.00 –000.00 -500.00 10 v
%ofFSR +100.00 –000.00 -100.00 0.01%
Two s
Complement
7FFF 0000 8000 1 LSB
1
04 – 1V
Engineering
Unite
+100.00 –0.0000 -1.0000 100.00 v
%ofFSR +100.00 –000.00 -100.00 0.01%
Two s
Complement
7FFF 0000 8000 1 LSB
1
05 – 2.5 V
Engineering
Unite
+2.5000 –0.0000 -2.5000 100.00 v
%ofFSR +100.00 –000.00 -100.00 0.01%
Two s
Complement
7FFF 0000 8000 1 LSB
1
06 – 20 mV
Engineering
Unite
+20.000 –00.000 -20.000 1 v
%ofFSR +100.00 –000.00 -100.00 0.01%
Two s
Complement
7FFF 0000 8000 1 LSB
1
07 not used
