B.4 Analog Output Ranges
Range
Code
(hex)
Input Range
Description
Data Formats
Maximum
Specitied
Signal
Minimum
Specitied
Signal
Output
Resolution
30 0to20mA
Engineering
Unite
20.000 00.000 5 A
% of FSR +100.00 +000.00 5 A
Hexadecimal
Binary
FFF 000 5 A
31 4to20mA
Engineering
Unite
20.000 04.000 5 A
% of FSR +100.00 +000.00 5 A
Hexadecimal
Binary
FFF 000 5 A
32 0to10V
Engineering
Unite
20.000 00.000 2.442 mA
% of FSR +100.00 +000.00 2.442 mA
Hexadecimal
Binary
FFF 000 2.442 mA
