Technical specifications
A-32 ADAM 4000 Series User's Manual
A.14 ADAM-4060 Relay Output Module
Table A-18 ADAM-4060 Specifications
Digital ouput 4-channel relay,
2 form A,
2 form C
Input RS-485 (2-wire)
speed (bps) 1200, 2400, 4800, 9600, 19.2K, 38.4K
maximum distance 4000 ft. (1200 m)
Contact rating AC: 0.6 A/125 V; 0.3 A/250 V
DC: 2 A/30 V; 0.6 A/ 110 V
Breakdown voltage 500 V
AC
(50/60 Hz)
Relay on time (typical) 3 msec
Relay off time (typical) 1 msec
Total switching time 10 msec
Insulation resistance 1000 MΩ minimum at 500 V
DC
Watchdog timer Yes
Power supply +10 to +30 V
DC
(non-regulated)
Power consumption 0.8 W
