Calibration
5-8 ADAM 4000 Series User's Manual
Module
Input Range
Code (Hex)
Input Range
Span Calibration
Resistance
Offset Calibration
Resistance
4013 20
140 Ω 60 Ω
21
140 Ω 60 Ω
22
200 Ω 60 Ω
23
440 Ω 60 Ω
24
140 Ω 60 Ω
25
140 Ω 60 Ω
26
200 Ω 60 Ω
27
440 Ω 60 Ω
28 Ni, -80 C to 100 C
200 Ω 60 Ω
29 Ni, 0 C to 100 C 200 Ω 60 Ω
5. Issue an Offset Calibration command to the module. This can be done
by either using the Calibrate option in the ADAM utility software (See
Appendix D, Utility Software)
6. Issue a Span Calibration command to the module. This can be done with
the Calibrate option in the ADAM utility software (See Appendix D,
Utility Software)
Table 5-2 Calibration Resistance
Pt, -100° C to 100° C
α = 0.00385
Pt, 0° C to 100° C
α = 0.00385
Pt, 0° C to 200° C
α = 0.00385
Pt, 0° C to 600° C
α = 0.00385
Pt, -100° C to 100° C
α = 0.003916
Pt, 0° C to 100° C
α = 0.003916
Pt, 0° C to 200° C
α = 0.003916
Pt, 0° C to 600° C
α = 0.003916
