ADAM-4000 Series User Manual 140
4015, 4015T, 4017+, 4018+, 4019+
5.1.18 $AA7CiRrr
Name Single Channel Range Configuration command
Description This command configures the input type and range of the
specified channel in an analog input module.
Syntax $AA7CiRrr(cr)
$ is a delimiter character.
AA (range 00-FF) represents the 2-character hexadecimal
address of the analog input module which is to be configured.
7 is the Single Channel Range Configuration command.
Ci represents the specified input channel you want to configure.
Rrr represents the type and range you want to set. (Refer to
Table 5.1 on Page 5-6 to check range codes)
(cr) is the terminating character, carriage return (0Dh).
Response !AA(cr) if the command was valid.
?AA(cr) if an invalid operation was entered.
There is no response if the module detects a syntax error or
communication error or if the specified address does not exist.
! delimiter character indicates a valid command was received.
? delimiter character indicates the command was invalid.
AA (range 00-FF) represents the 2-character hexadecimal
address of the analog input module.
(cr) represents terminating character, carriage return (0Dh).
Example command: $027C5R21(cr)
response: !02(cr)
The command configures the range of channel 5 in the
analog input module at address 02 as Pt100(IEC) 0 ~ 100 °C
