ADAM-4000 Series User Manual 148
4018M
5.2.3 @AAD
Name Read Memory Configuration command
Description The command requests the configuration data from the
analog input data logger at address AA.
Syntax @AAD (cr)
@ is a delimiter character.
AA (range 00-FF) represents the 2-character hexadecimal
address of an analog input data logger.
D is the Read Memory Configuration command.
(cr) is the terminating character, carriage return (0Dh).
Response !AACCSDMTTTT(cr) if the command is valid.
! is a delimiter character indicating a valid command was received.
AA (range 00-FF) represents the 2-character hexadecimal
address of an analog input data logger.
CC (range 00-FF) represents the data storage status of each
channel. The ADAM-4018M has 8 channels, bit 0
representing channel 0, and bit 7 representing channel 7. A
mask bit value of ‘1’ enables data storage in the specified
channel, while a mask bit value of ‘0’ disables data storage.
S represents the standalone mode. In order for the
ADAM-4018M to operate in the field, you must power on
the memory module by setting this value to ‘1.’ Otherwise,
the data will not be recorded.
D represents the data logging mode. ‘0’ enables Standard
Mode, where all eight channels record the normal data
according to the sampling interval. ‘1’ enables Event Mode,
where all eight channels record the data if its value is over
the High Alarm limit or under the Low Alarm limit. ‘2’
enables Mixed Mode, where channels 0 ~ 3 act as the
standard logger and the channels 4 ~ 7 act as the event logger.
M represents the storage type. "0" represents writing to the
end of memory. "1" represents circular memory mode.
TTTT (range 2-65535) represents the sampling interval in seconds.
(cr) is the terminating character, carriage return (0Dh).
