Advantech ADAM-5510/P31 User Manual

C-4 ADAM-5510/P31
Data Formats and I/O Ranges
C.2 Analog Input Ranges - ADAM-5017
Module Range
Code
Inp ut Rang e
Description
Data
Formats
+F.S. Zero -F.S. Displayed
Resolution
Actual
Value
ADAM-
5017
08h ±10 V
Engineering
Units
+10.000 ±00.000 -10.000 1 mV
Reading/
1000
09h ±5 V
Engineering
Units
+5.0000 ±0.0000 -5.0000 100.00 µV
Reading/
1000
0Ah ±1 V
Engineering
Units
+1.0000 ±0.0000 -1.0000 100.00 µV
Reading/
10000
0Bh ±500 mV
Engineering
Units
+500.00 ±000.00 -500.00 10 µV
Reading/
10
0Ch ±150 mV
Engineering
Units
+150.00 ±000.00 -150.00 10 µV
Reading/
100
0Dh ±20 mA
Engineering
Units
+20.000 ±00.000 -20.000 1 µV
Reading/
1000
