Advantech ADAM-5510/P31 User Manual

ADAM-5510/P31 C-5
Appendix C
C.3 Analog Input Ranges - ADAM-5018
Module Range
Code
Inp ut Rang e
Description
Data
Formats
+F.S. Zero -F.S. Displayed
Resolution
Actual
Value
ADAM-
5018
00h ±15 mV
Engineering
Units
+15.000 ±00.000 -15.000 1 µV
Reading/
1000
01h ±50 mV
Engineering
Units
+50.000 ±00.000 -50.000 1 µV
Reading/
100
02h ±100 mV
Engineering
Units
+100.00 ±000.00 -100.00 10 µV
Reading/
100
03h ±500 mV
Engineering
Units
+500.00 ±000.00 -500.00 10 µV
Reading/
10
04h ±1 V
Engineering
Units
+1.0000 ±0.0000 -1.0000 100 µV
Reading/
10000
05h ±2.5 V
Engineering
Units
+2.5000 ±0.0000 -2.5000 100 µV
Reading/
10000
06h ±20 mA
Engineering
Units
+20.000 ±00.000 -20.000 1 µA
Reading/
1000
07h Not Used
