Advantech ADAM-5510/P31 User Manual

ADAM-5510/P31 C-7
Appendix C
C.4 Analog Input Ranges - ADAM-5017H
Note: The full scale values in this table are theoretical
values for your reference; actual values will vary.
Range
Code
Input Range Data
Formats
+Full
Scale
Zero -Full Scale Displayed
Resolution
Actual
Value
00h ±10 V Engineering 11 0 -11 2.7 mV Reading/
1000
Two's Comp 0FFF 0 EFFF 1
01h 0 ~ 10 V Engineering 11 0 Don't care 2.7 mV Reading/
1000
Two's Comp 0FFF 0 Don't care 1
02h ±5 V Engineering 5.5 0 -5.5 1.3 mV Reading/
1000
Two's Comp 0FFF 0 EFFF 1
03h 0 ~ 5 V Engineering 5.5 0 Don't care 1.3 mV Reading/
1000
Two's Comp 0FFF 0 Don't care 1
04h ±2.5 V Engineering 2.75 0 -2.75 0.67 mV Reading/
10000
Two's Comp 0FFF 0 EFFF 1
05h 0 ~ 2.5 V Engineering 2.75 0 Don't care 0.67 mV Reading/
10000
Two's Comp 0FFF 0 Don't care 1
06h ±1 V Engineering 1.375 0 -1.375 0.34 mV Reading/
10000
Two's Comp 0FFF 0 EFFF 1
07h 0 ~ 1 V Engineering 1.375 0 Don't care 0.34 mV Reading/
10000
Two's Comp 0FFF 0 Don't care 1
08h ±500 mV Engineering 687.5 0 -687.5 0.16 mV Reading/
10
Two's Comp 0FFF 0 EFFF 1
09h 0 ~ 500 mV Engineering 687.5 0 Don't care 0.16 mV Reading/
10
Two's Comp 0FFF 0 Don't care 1
0ah 4 ~ 20 mA Engineering 22 4.0 Don't care 5.3 µA Reading/
1000
Two's Comp 0FFF 02E9 Don't care 1
0bh 0 ~ 20 mA Engineering 22 0 Don't care 5.3 µA Reading/
1000
Two's Comp 0FFF 0 Don't care 1
