MIO-5250 User Manual
Appendix A
Pin Assignments
CN7
Reset
Part Number
165
5302020
Footprint
WF_2P_79_BOX_R1_D
Description
WAFER BOX 2P 2.0mm 180D(
M) DIP A2001WV2-2P
Pin
Pin Name
1
RESET#
2G
N
D
CN9
GPIO
Part Number
165
3004099
Footprint
HD_5x2P_79_2
3N685B-10M10
Description
BOX HEADER 5x2P 2.00mm 180D(M) SMD 23N685B-10M10
Pin
Pin Name
1+
5
V
2G
P
I
O
4
3G
P
I
O
0
4G
P
I
O
5
5G
P
I
O
1
6G
P
I
O
6
7G
P
I
O
2
8G
P
I
O
7
9G
P
I
O
3
10
GND
46
48
