PCI-1752 User Manual 2
Chapter 1 Introduction
Thank you for buying the Advantech PCI-1752U/PCI-1752USO isolated
digital output card. The Advantech PCI-1752U/PCI-1752USO isolated
digital output card is a powerful data acquisition card for both 3.3/ 5V
PCI bus. It features a unique circuit design and complete functions for
data acquisition and control. PCI-1752U/PCI-1752USO provides 64 iso-
lated digital output channels. The following sections of this chapter will
provide further information about features of PCI-1752U/PCI-1752USO,
a Quick Start for installation, together with some brief information on
software and accessories.
1.1 Features
The Advantech PCI-1752U/PCI-1752USO DAS cards provide users with
the most requested measurement and control functions as seen below:
PCI-1752 DAS card
 64 isolated digital output channels
 High-voltage isolation on output channels (2,500 V
DC )
 Wide output range (5 ~ 40 V
DC )
 High-sink current for isolated output channels (200 mA max./ch)
 Board ID
 Output status read-back
 Digital output value retained after hot system reset
 Channel-Freeze function
 Output status read-back
The PCI-1752U/PCI-1752USO DAS cards offer the following main fea-
tures:
Robust Protection
The PCI-1752U/PCI-1752USO features a robust isolation protection for
applications in industrial, lab and machinery automation. The PCI-
1752U/ USO can durably withstand a voltage up to 2,500 V
DC
, prevent-
ing your host system from any incidental harms.
