PCI-1752 User Manual 10
Note: If the autoplay function is not enabled on your computer, use
Windows Explorer or Windows Run command to execute
AUTORUN.EXE on the companion CD-ROM.
Step 3: Click Continue, and select the Installation option.
Step 4: Select the specific device and then just follow the installation
instructions step by step to complete your device driver installation and
setup.
For further information on driver-related issues, an online version of the
Device Drivers Manual is available by accessing the following path:
Start\Programs\Advantech Automation \Advantech Device Man-
ager\Device Driver’s Manual.
2.3 Hardware Installation
Note: Make sure you have installed the driver first before you install the
card (please refer to Section 2.2 Driver Installation)
After the DLL driver installation is completed, you can now go on to
install the PCI-1752U/PCI-1752USO card in any PCI slot on your com-
puter. But it is suggested that you should refer to the computer user man-
ual or related documentations if you have any doubt. Please follow the
steps below to install the card on your system.
Step 1: Turn off your computer and unplug the power cord and cables.
TURN OFF your computer before installing or removing any com-
ponents on the computer.
Step 2: Remove the cover of your computer.
Step 3: Remove the slot cover on the back panel of your computer.
Step 4: Touch the metal part on the surface of your computer to neutralize
the static electricity that might be on your body.
Step 5: Adjust DIP switch SW1 on board to set the card’s board ID.
Step 6: Insert the PCI-1752U/PCI-1752USO card into a PCI slot. Hold
the card only by its edges and carefully align it with the slot. Insert the
card firmly into place. Use of excessive force must be avoided, otherwise
the card might be damaged.
Step 7: Fasten the bracket of the PCI card on the back panel rail of the
computer with screws.
Step 8: Connect appropriate accessories (100-pin cable, wiring termi-
nals, etc. if necessary) to the PCI card.
