PCI-1752 User Manual 30
Appendix A Specifications
Isolated Digital Output
General
1
Throughput rate depends on the computer hardware architecture and
software environment. The rates may vary due to programming language,
code efficiency, CPU utilization and so on.
Table A.1: Isolated Digital Output
Number of Output Channels PCI-1752 64
Optical Isolation 2500 V
DC
Throughput
10 kHZ
1
Supply Voltage 5 ~ 40 V
DC
Sink Current 200 mA max/channel
Table A.2: General Specifications
I/O Connector Type 100-pin SCSI-II female
Dimensions 175 mm x 100 mm (6.9" x 3.9")
Power Consumption Typical +5V @ 230 mA
Max. +5V @ 500 mA
Temperature Operation 0 ~ +60 °C (32 ~ 140 °F)
(refer to IEC 68-2-1,2)
Storage -20 ~ +70 °C (-4 ~ 158 °F)
Relative Humidity 5 – 95 % RH non-condensing
(refer to IEC 68-2-3)
