11 SIMB-M21 User Manual
Chapter 2 Product Introduction
2.3.5 Internal Connector
Table 2.3: Rear Panel Connector
Label Function Note Page
KBMS PS/2 Keyboard and Mouse 6-pin Mini-Din 29
COM1 COM1 Connector D-sub 9-pin, male 29
DP1 DisplayPort Connector DisplayPort
VGA1 VGA Port D-sub 15-pin, female 29
HDMI1 HDMI Port HDMI 1.3 19-pin 29
LAN1USB12
RJ-45 Ethernet Connector x 1
USB 2.0 Connector x 2
29
LAN2USB34
RJ-45 Ethernet Connector x 1
USB 2.0 Connector x 2
Audio1 Audio Line-In , Line-Out , Mic.-In 5.1 Channel Audio I/O (3 jacks) 29
Table 2.4: Internal Connector
Label Function Note Page
CPU_FAN1 CPU Fan Connector 3 x 1 wafer, pitch 2.54mm 26
SYS_FAN1 System Fan Connector 3 x 1 wafer, pitch 2.54mm 26
COM3 ~ 5 Serial Port Connector * 3 5 x 2 header, pitch 2.54mm 29
JGPIO GPIO Connector 5 x 2 header, pitch 2.54mm 29
F_PANEL Intel Front Panel connector 5 x 2 header, pitch 2.54mm 30
EATXPWR1 ATX power connectors 10 x 2 header 28
FPAUD1 Audio Mic.-In & Line-Out Connector 5 x 2 header, pitch 2.54mm 30
JLVDS 24-bit LVDS Connector 2 x 20 connector
JLVDS_BKL2 LCD Inverter Connector 1 x 5 connector
SPI SPI Connector 4 x 2 header, pitch 2.54mm 32
SATA1 ~ 5 SATA Data Connector * 5 7P Male connector 33
USB45
USB89
USB1011
USB Connector * 6 5 x 2 header, pitch 2.54mm 35
To Next Page
