3 SIMB-M21 User Manual
Chapter 1 Product Overview
2 x LAN RJ45 Ports,
1 x Audio I/O (3 Jacks)
Internal I/O:
3 x USB Connectors supports 6 USB Ports,
3 x COM RS-232 Connectors with 5V/ 12V Power,
5 x SATA Connectors (2 SATA 3.0, 3 SATA II),
1 x Front Panel Connector,
1x Front Audio,
1 x CPU Fan Connector (3-pin),
1 x System Fan Connector (3-pin),
1 x LVDS (2 x 20-pin),
1 x LVDS Backlight Power Connector,
1 x Clear CMOS Jumper (3-pin),
1 x GPIO
1.1.7 Mechanical & Environmental
* Specifications are subject to change without notice.
Power Requirement
+12V (4.86A), +5V (1.28A), +3.3V (1.05A), -12V (0.41A), 5VSB
(0.36A)
Power Type ATX (supports AT Mode)
Power Connector
1 x 20-pin ATX Power Connector,
1 x 4-pin ATX 12V Power Connector
Operating Temperature 0° C to 50° C (32° F to 122° F)
Operating Humidity 0% to 90% relative humidity, non-condensing
Size (L x W) 6.69" x 6.69" (170 x 170mm)
Weight 1.03 lbs (0.47 Kg)
