19 SIMB-M21 User Manual
Chapter 2 Product Introduction
2.5.4 Removing a SO-DIMM
1. Simultaneously press the retaining clips downward to unlock the DIMM.
2. Remove the DIMM from the socket.
2.6 Expansion Card
In the future, you may need to install expansion cards. The following sub-sections
describe the slots and the expansion cards that they support.
Caution! Make sure to unplug the power supply before adding or removing SO-
DIMMs or other system components. Failure to do so may cause severe
damage to both the motherboard and the components.
Note! Support the SO-DIMM lightly with your fingers when pressing the retain-
ing clips. The SO-DIMM might get damaged when it flips out with extra
force.
Warning! Make sure to unplug the power cord before adding or removing expan-
sion cards. Failure to do so may cause you physical injury and damage
motherboard components.
