UNO-148 User Manual 4
1.4.2 System Hardware
BIOS AMI UEFI 256Mbit
Watchdog Timer Programmable 255 levels timer interval, from 1 to 255 sec
Hardware Security TPM 2.0
Processor Intel Core™ 1.8GHz (up to 4.4GHz)
Memory
2 Slot Built-in 8GB DDR4L 3200MHz (Up to 32GB per Slot, Up to 64
GB totally)
Graphics Engine
Intel
®
Iris
®
Xᵉ
Ethernet
Intel
®
i210-IT GbE, IIEEE802.1AS, 802.3az
Intel
®
i219
Intel
®
i225 2.5Gb/s, IIEEE1588 protocol and 802. 1AS implementation
LED Indicators
1x Power: Green-S0, Orange S3 or S5)
1x RUN: Green-Programmable (PLED)
1x BTR: RED-RTC Battery Low
Communication M.2 slot for B key and E key
Storage
1 x M.2 M key 2280 NVMe SSD (PCIex4 Signal)
1 x M.2 B-key 2242 (SATA Signal)
Expansion
1 x 2.5” 2242 SSD/HDD (Plug in a riser card in expansion unit)
1 x M.2 B-key 3042 or 3052 Module (USB3.2 Gen2 Signal)
1 x Nano SIM card slot for B-key use
1 x M.2 E-key 2230 WiFi module (PCIe/USB2.0 Signal)
1 x E-key miniPCIe (PCIe/USB2.0 Signal)
Note! The M.2 B-key can support either 2242 storage (w/ SATA signal) or
3042/3052 Module (w/ USB signal).
