5 UNO-148 User Manual
Chapter 1 Overview
1.4.3 I/O Interfaces
1.4.4 Environment
1.4.5 Certification
Serial Ports
4 x RS-232/422/485 (terminal block), 50 ~115.2 kbps (Isolation
Protection: 2500 V
DC
)
LAN Ports
1x Intel I225 Ethernet Chip
1x Intel I219 Ethernet Chip
1x Intel I210 Ethernet Chip
Speed
1 x 10/100/1000/2500 Mbps IEEE 802.3u 2500BASE-T Fast
Ethernet (RJ-45)
USB Ports 3 x USB 3.2 Gen2, and 1 x USB 2.0 (Type A)
Isolated DIO
8-ch digital input, 8-ch digital output (Isolation Protection:
2500V
DC
)
Input Voltage (Wet Contact)
Logic 0:10~30 V
DC
Logic 1: 0~3 V
DC
Input Voltage (Dry Contact)
Logic 0: Shorted to GND
Logic 1: Open
Digital Output
Output Voltage:5~30 V
DC
Output Capability Sink:500mA max./channel
Displays 2 x DP 1.4, up to 7680x3480 (8K) @ 60Hz
Power Connector 1 x 2 Pin (terminal block)
Operating Temperature* -20 ~ 60° C (-4 ~ 140° F) with 0.7m/s airflow
Storage Temperature - 40 ~ 85 °C (-40 ~ 185 °F)
Relative Humidity 95% RH @ 40 °C/104 °F, non-condensing
Shock Protection Operating, IEC 60068-2-27, 50G, half sine, 11ms
Vibration Protection
Operating, IEC 60068-2-64, 4Grms, random, 5 ~500Hz, 1hr/
axis (SSD)
Operating, IEC 60068-2-64, 0.3 Grms, random,5 ~ 500Hz, 1hr/
axis (HDD)
Note! It is recommended to use 2.5" SSD under the temperature of 60° C/140°
F.
Certification CE, FCC, CB, UL 61010-2-201, BSMI
