advantest corporation TR5821 - Table of Contents

CONTENTS
SECTION 1 GENERAL INFORMATION
1-1. General......................................................................................1-1
1-2. C au tion ...................................................................................1 -2
SECTION 2 SPECIFICATIONS
2-1. Electrical Performance...........................................................2—1
2-2. General Specifications............................................................2—3
2-3. Options ...................................................................................2-4
24. Accessories Supplied .............................................................. 2-5
SECTION 3 OPERATIONS
3-1. Preparation and Cautions before Use ................................ 3—1
3-2. Description of Panels ............................................................. 3—5
3-3. Basic Operating Procedure...................................................3-12
3-3*1. Self-diagnostics Function...........................................3—12
3-3-2. Error Messages............................................................. 3-13
3-3-3. Panel Switch Check..................................................... 3—14
3-3-4. Frequency Measurement...........................................3—15
3-3-5. Period Measurement...................................................3-1 8
3-3-6. Time Interval Measurement ..................................... 3-1 8
3-3-7. Frequency Ratio Measurement ................................3—19
3-3-8. Totalize........................................................................ 3—20
3-3-9. M asking ........................ .. ............................................. 3—21
3-3-10. High-frequency Fuse Replacement .......................... 3—22
SECTION 4 GPIB INTERFACE
4-1. Introduction...........................................................................4—1
4-2. General Outline of the GPIB
.................................................4 -1
4-3. Specifications .........................................................................4—3
44. Data Formats............................................................................ 4—5
4-5. GPIB Operating Procedures .................................................4-10
4-6. Programming N otes.................................................................4—15
