Newswift 90-180 Motorised Antenna 39
Alarms
Command: QUE
Response: UEwwwwxxxxyyyyzzzz
wwww Alarm1 coded status
xxxx Alarm2 coded status
yyyy Alarm3 coded status
zzzz Alarm4 coded status
Alarm coded status: Hexadecimal coding. Fixed length.
UAlarm 1U Bit 1 LSB +12V Power supply voltage low.
Bit 2 +36V Motor supply voltage failure.
Bit 3 Motor drive inhibit.
Bit 4 Inclinometer Failure.
Bit 5 Inclinometer suspect. (Deployed only)
Bit 6 Drive stall detected.
Bit 7 Drive freewheel detected.
Bit 8 Drive travel limit detected.
Bit 9 Waveguide switch failure.
Bit 10 Azimuth stow sensor failure.
Bit 11 Elevation stow sensor failure.
Bit 12 Polarization stow sensor failure.
Bit 13 Stow 4 sensor failure.
Bit 14 Stow 5 sensor failure.
Bit 15 Stow 6 sensor failure.
Bit 16 MSB FPGA programming failure.
UAlarm 2U Bit 1 LSB Manual brake override active.
Bit 2 Azimuth stowing failure.
Bit 3 Elevation stowing failure.
Bit 4 Polarization stowing failure.
Bit 5 Axis 4 stowing failure.
Bit 6 Axis 5 stowing failure.
Bit 7 Power up state suspect.
Bit 8 Stow sensor supply error
Bit 9 MRD supply error
Bit 10 Inclinometer supply error
Bit 11 FPGA watchdog triggered.
Bit 12 GPS communications failure.
Bit 13 Compass communications failure.
Bit 14 Feed drive failure.
Bit 15 Hand held controller override active.
Bit 16 MSB ACU-DCU serial link failure. (ACU use only.)
