VISLINK
Newswift 90-180 Motorised Antenna 40
UAlarm 3U Bit 1 LSB Fin 1 over temperature.
Bit 2 Fin 2 over temperature.
Bit 3 Fin 3 over temperature.
Bit 4 Fin 4 over temperature.
Bit 5 Fin 5 over temperature.
Bit 6 WGS supply failure.
Bit 7 Brake supply failure.
Bit 8 Fan supply failure.
Bit 9 Feed supply failure.
Bit 10 GPS/Compass supply failure.
Bit 11 Status supply failure.
Bit 12 Azimuth brake disconnected.
Bit 13 Elevation brake disconnected.
Bit 14 Polarisation brake disconnected.
Bit 15 Axis 4 brake disconnected.
Bit 16 MSB Axis 5 brake disconnected.
UAlarm 4U Bit 1 LSB Main unit fan over MTBF.
Bit 2 Heatsink fan over MTBF.
Bit 3 E
P
2
P
PROM Checksum error.
Bit 4 Softlimit data error. Reverted to defaults
Bit 5 Wooded area data error. Reverted to defaults.
Bit 6 Calibration area data error. Reverted to defaults.
Bit 7 FPGA compatibility warning.
Bit 8 External Flash Erasing/writing error.
Bit 9 Antenna Type Alarm.
Bit 10 Heatsink fan stall detected. (DCU5000 only)
Bit 11 HMR3300 temperature warning.
Bit 12 HMR3300 temperature alarm.
Bit 13 Not used.
Bit 14 Not used.
Bit 15 Not used.
Bit 16 MSB Not used.
Test Tab Measure Results
Command:
Response: TTR±xxxxx±yyyyy±aaaaa±bbbbb
Returned after the successful completion of a force axis tab measurement, in
response to a QUD message. (Test Mode only)
±xxxxx Edge 1. CW 1a Fixed length, units 0.01°.
±yyyyy Edge 2. CW 2a
±aaaaa Edge 3. ACW 2b
±bbbbb Ed
g
e 4.
A
CW 1b
