Page 38 AD Series Dehumidifying Dryers
Press and to set the higher or lower the values of a
parameter or turn that function On or Off.
Press
Level Key once to return to the Process Temperature
Setting.
Figure 8
Setting List for Process Temperature Controller (E5CN), Part No. A0555757
Mode Parameter Setting range Default AEC setting
Operation Run/Stop Run/Stop Run -
Operation Alarm value 1 -1999 to 9999 0 25
Mode Parameter Setting range Default AEC setting
Adjustment AT execute/cancel ON, OFF OFF ?
Adjustment Temperature input shift -199.9 to 999.9 0.0 -
Adjustment Proportional Band 0.1 to 999.9 8.0 ?
Adjustment Integral Time 0 to 3999 233 ?
Adjustment Derivative Time 0 to 3999 40 ?
5-7 Process Air Dew Point Display
Optional
The Process Air Dew Point meter indicates the current process air
delivery moisture content. Standard AEC dryers use a
microprocessor-based controller for displaying dew point air
temperature. The controller is a modular, self-contained unit
removable from the mounting housing. All parameters are factory
set and adjusted; normally, no field adjustment to the internal
controls are necessary.
