Page 42 AD Series Dehumidifying Dryers
Figure 11
Setting List for Redundant Safety Controller (WATLOW), Part No. A0555757
Mode Parameter Setting range Default AEC setting
SEn Sensor Type 0-3 0 -
Lin
Thermocouple
Linearization
0-10 0 H (1)
C-F Temperature Units Fahrenheit / Celsius F -
S.dEC Temp. Decimal Places 0 – 0.0 0 -
IS.En INFOSENSE™ Yes / No No -
Sc.Lo Process Scale Low 4.00 to 20.00 mA
1.00 to 10.00V
4.00 mA
1.00V
0
Sc.hi Process Scale High 4.00 to 20.00 mA
1.00 to 10.00V
20.00 mA
5.00 V
400
CAL Calibration Offset -999 to 999 0 -
Ftr.E Input Filter Off, DiSP, Cont, both OFF -
Ot 1 Output 1 Function Limit (2) (2) -
LSd1 Output 1 Limit Sides Both, High, Low Both High
hyS1 Limit 1 Hysteresis 0.0 to 999.0 1.0 -
Ot2 Output 2 Function Off / Process Alarm / Limit (2) OFF -
LSd2 Output 2 Sides Both / high / low Both -
UdSP Upper Display Look
None, Process Value, Limit 1 Low
Set, Limit 1 High Set, Limit 2 Low
Set, Limit 2 High Set, Alarm 2 Low
Set, Alarm 2 High Set, Limit 3 Low
Set, Limit 3 High Set, Alarm 3 Low
Set, Alarm 3 High Set
Process -
LdSP Lower Display Look
None, Process Value, Limit 1 Low
Set, Limit 1 High Set, Limit 2 Low
Set, Limit 2 High Set, Alarm 2 Low
Set, Alarm 2 High Set, Limit 3 Low
Set, Limit 3 High Set, Alarm 3 Low
Set, Alarm 3 High Set
Limit 1
High Set
-
LOC Lockout
(0) no lockout, (1) Programming
and Setup Page Locked, (2) Limit
Set Points are the only Operation
Page parameters accesible, (3) Full
Lockout.
02
