AEC AD Series - 11 Spare Parts; Spare Parts List; Level 1 Spare Parts List (Electrical & Mechanical)

Page 68 AD Series Dehumidifying Dryers
11 Spare Parts
11-1 Spare Parts List
AD Series Dehumidifying Dryers
Figure 17
Level 1 Spare Parts List
(Electrical & Mechanical)
MINI DRYER SPARE PARTS LIST AD15, AD30, AD60
15CFM 15CFM 15CFM 15CFM 15CFM 15CFM 30CFM 30CFM 30CFM 30CFM 30CFM 30CFM 60CFM 60CFM 60CFM 60CFM 60CFM 60CFM
LEVEL 1 ( Electrical Components )
208V 3PH
220V 50 HZ 3PH
230V 3PH
400V 50 HZ 3PH
460V 3PH
575V 60 HZ 3PH
208V 3PH
220V 50 HZ 3PH
230V 3PH
400V 50 HZ 3PH
460V 3PH
575V 60 HZ 3PH
208V 3PH
220V 50 HZ 3PH
230V 3PH
400V 50 HZ 3PH
460V 3PH
575V 60 HZ 3PH
PART # SIZE Description
A0568932 2 Fuse for the Heater Elements 3
A0568933 2.5 Fuse for the Heater Elements 3 3
A0568934 3 Fuse for the Heater Elements 3
A0534039 3.5 Fuse for the Heater Elements 3
A0534040 4 Fuse for the Heater Elements 3
A0534041 5 Fuse for the Heater Elements 3 3 3 3
A0534042 6 Fuse for the Heater Elements 3 3 3
A0534043 7 Fuse for the Heater Elements 3 3 3 3
A0534044 8 Fuse for the Heater Elements 3 3 3 3
A0534046 10 Fuse for the Heater Elements 3
A0534047 12 Fuse for the Heater Elements 3 3
A0534048 15 Fuse for the Heater Elements 3 3 3 3 3 3 3
A0534049 20 Fuse for the Heater Elements 3 3
A0568936 25 Fuse for the Heater Elements 33
A0434051 30 Fuse for the Heater Elements 3
A0568909 1 Fuse for the Process Blower 3
A0568910 1.125 Fuse for the Process Blower 3
A0568911 1.25 Fuse for the Process Blower 3
A0534804 2 Fuse for the Process Blower 3
A0568917 2.5 Fuse for the Process Blower 3 3 3
A0550577 3 Fuse for the Process Blower 3
A0568919 3.2 Fuse for the Process Blower 3
A0568921 4.5 Fuse for the Process Blower 3
A0550593 5.6 Fuse for the Process Blower 3 3
A0538062 6 Fuse for the Process Blower 3
A0568922 6.25 Fuse for the Process Blower 3
A0568923 7 Fuse for the Process Blower 3
A0568926 10 Fuse for the Process Blower 3
A0538069 12 Fuse for the Process Blower 33
A0536892 1.25 Fuse for the transformer 2 2 2
A0536894 1.6 Fuse for the transformer 2 2 2
A0536895 1.8 Fuse for the transformer 2 2 2
A0538001 3.2 Fuse for the transformer 2 2 2 2 2 2
A0538002 3.5 Fuse for the transformer 2 2 2
A0568941 2.8 Fuse for the transformer 1 (ALL)
A0558078 0.3-1 Motor Overload 1 1
A0558079 1-2.9 Motor Overload 1 1 1 1 1 1 1 1 1 1 1 1 1
A0558082 1.6-5 Motor Overload 111
LEVEL 1 ( Mechanical Components )
PART # SIZE Description
W00015435 Dew Point Sensor Insert Cable 1 1 1
A0548556 Dew Point Sensor 1 1 1
A0566467 Valve switch 1 1 1
A0566531 Process Air Filter 1 1 1
W00018051 13X molecular Sieve Desiccant ( 8 X 12 Beads ) 4.75 Lbs. 12.25 Lbs. 27.5 Lbs.
W00013983 High Temperature Gasket. 135 Inches 163 Inches 188 Inches
A0566676 High Temperature Snap Switch. 3 3 3
