12
Operating parameter Available at the page Description
Suction temperature 2
3
Compressor 2 intake temperature
Shell-and-tube inlet-T 1 Shell and tube heat exchanger 1 input temperature
Plate-H-EXCHG inlet-T 1 (*)
Inlet temperature 1 of plate heat exchangers
Shell-and-tube inlet-T 2 Shell and tube heat exchanger 2 input temperature
Plate-H-EXCHG inlet-T 2 (*)
Inlet temperature 2 of plate heat exchangers
Shell-and-tube outlet-T 1 Shell and tube heat exchanger 1 output temperature
Plate-H-EXCHG outlet-T 1 (*)
Outlet temperature 1 of plate heat exchangers
Shell-and-tube outlet-T 2 Shell and tube heat exchanger 2 output temperature
Plate-H-EXCHG outlet-T 2 (*)
Outlet temperature 2 of plate heat exchangers
Water-T for energy saving
4
Water production temperature with climatic curve
High pressure sensor 1 High pressure transducer 1 value
High pressure sensor 2 High pressure transducer 2 value
(*) For the HMG-P series
Note:
— if the temperature value is invalid or absent, the letters "N/A" are shown
— for the "Anti-freezing-T" and "Anti-over-heating-T" parameters, only the "An-
ti-freezing-T" parameter will be visualised if the set mode is "cool"; if any other
mode is set, only the "Anti-over-heating-T" parameter will be visualised
(3) Error:
Pressing the "Error" button will take you to information about errors on the unit;
Note: the system will display the active errors on the unit, oering a list if there
are more than one (if more than 5, they will be divided into pages, which can be
changed using the arrow keys on the right and left side of the window);
List of alarms
N. Visualisation Description
1
Jumper error Error relating to the jumper
2
Flow meter alarm Flow switch error
3
Sys1 H-discharge-T High discharge temperature protection 1
4
Sys2 H-discharge-T High discharge temperature protection 2
5
Low Discharge T1 Low discharge temperature 1
6
Low Discharge T2 Low discharge temperature 2
7
Sys1 high pressure High pressure alarm1
8
Sys2 high pressure High pressure alarm 2
9
Sys1 low pressure Low pressure alarm 1
10
Sys2 low pressure Low pressure alarm 2
11
Entering water TSE Water inlet probe error
12
Leaving water TSE Water outlet probe error
13
Anti-F/anti-H TSE Anti-freeze/anti-overheating probe error
14
Outdoor TSE Outdoor temperature sensor error
15
Defrosting TSE1 Defrosting probe error 1
16
Defrosting TSE2 Defrosting probe error 2
17
Dis-TSE1 malfunction Temperature probe error on discharge 1
18
Dis-TSE2 malfunction Temperature probe error on discharge 2
19
Shell&tube inlet TSE1 Temperature probe error on inlet of shell & tube heat exchanger 1
20
Shell&tube inlet TSE2 Temperature probe error on inlet of shell & tube heat exchanger 2
21
Suction TSE1 Temperature probe error on intake 1
22
Suction TSE2 Temperature probe error on intake 2
23
Pressure TSE1 Error on pressure sensor 1
24
Pressure TSE2 Error on pressure sensor 2
25
Commu-E comp1 Communication error between driver and compressor 1
26
Commu-E comp2 Communication error between driver and compressor 2
27
Commu-E fan1 Communication error between driver and fan 1
28
Commu-E fan2 Communication error between driver and fan 2
29
Shell&tube outlet TSE1 Temperature probe error on outlet of shell & tube heat exchanger 1
30
Shell&tube outlet TSE2 Temperature probe error on outlet of shell & tube heat exchanger 2
31
Failure of pump1 Pump protection 1
32
Failure of pump2 Pump protection 2
33
Fan1 error Fan error 1
34
Fan2 error Fan error 2
35
Over-current-proF1 Over-current protection of xed frequency fan 1
36
Over-current-proF2 Over-current protection of xed frequency fan 2
37
DC under-voltageC1 DC busbar under-voltage or voltage drop error of compressor 1
38
DC over-voltageC1 DC busbar over-voltage or voltage drop error of compressor 1
39
IPM errorC1 IPM module error on compressor 1
40
Startup failureC1 Startup failure of compressor 1
41
Dri-Mod resettingC1 Compressor 1 driver reset
42
Comp-Over-currentC1 Compressor 1 overcurrent
43
Current circuit SEC1 Current sensing circuit error or current sensor error of compressor 1
44
DesynchronizingC1 Desynchronizing of compressor 1
45
Comp-Dri-Comm-EC1 Communication error with driver compressor 1
46
HS-IPM-PFC over-TC1 Heat sink or IPM or PFC over-temperature of compressor 1
47
HS-IPM-PFC SEC1 Heat sink or IPM or PFC temperature sensor error of compressor 1
48
Charging circuit-EC1 Charging circuit error of compressor 1
49
DC under-voltageC2 DC busbar under-voltage or voltage drop error of compressor 2
50
DC over-voltageC2 DC busbar over-voltage or voltage drop error of compressor 2
51
IPM errorC2 IPM module error on compressor 2
52
Startup failureC2 Startup failure of compressor 2
53
Dri-Mod resettingC2 Compressor 2 driver reset
