19
18.03. 5719210_03
ANL / 290-650
EN
to(U)phase,(N)neutral,(PE)earthinthecase
ofsinglephaseunits(230V/50Hz),
8. U-V-Wforphases,NforneutralandPE
forearthinthecaseofthreephaseunits
(400V/3N/50Hz).
9. Replacetheinspeconpanels.
10. Ensurethatallproteconremovedfortheelec-
tricalconneconarereplacedbeforepowering
theunit.
11. Placethemainisolator(externaltotheunit)
to“ON.
 
 
Itisremindedthatforunitsofthisseries,ifrequested
bytheAermecclientorthelegalownerandonly
onITALIANterritory,freestart-upisprovidedbythe
regionalAermectechnicalassistanceservice.The
start-upmustbepreviouslyagreedbasedonthe
intendedmeofcompleonofinstallaon.Beforethe
start-upalltheworks(electricalandhydraulicconnec-
ons,llingandvenngofairinthesystem)mustbe
completed.
 
 

:
1. Allsafetyprecauonshavebeenfollowed.
2. Theunithasbeenappropriatelyxedtothe
supportbase.
3. Minimumclearancespaceshavebeenob-
served.
4. Powersupplycablesarecorrectlysizedandca-
pableofsupporngtheelectricalrequirements
oftheunit(seesecononelectricaldata)and
thattheunitiscorrectlyearthed.
5. Allelectricalconneconsarecorrectlytermi-
natedandghtened.
 
1. Applypowertotheunitbyturningthemainiso-
latortotheONposition.Thedisplaywillpower
upafterseveralsecondsafterapplyingpower,
checkthattheoperatingstatusisonOFF(OFFBY
KEYBonthelowerpartofthedisplay).
2. Checkwithatesterthatthepowersupplyvolt-
agesonthephasesU-V-Ware400V±10%,check
thatthephaseimbalanceisnotgreaterthan3%.
3. Checkthattheconnectionsmadebytheinstaller
complywiththedocumentation.
4. Checkthatthecompressorcrankcaseheater(s)
areoperatingbymeasuringtheincreaseofoil
sumptemperature.Theheater(s)mustbein
operationforatleast24hoursbeforestarting
thecompressor,andinallcasesthesumpoil
temperaturemustbe10-15Kaboveambient
temperature.

1. Checkthatallhydraulicconnectionshavebeen
correctlyinstalled,thattheinstructionsonthe
labelshavebeenfollowed,andthatamechani-
calfilterhasbeeninstalledontheinlettothe
evaporator.(Mandatorycomponentotherwise
thewarrantywillbevoided).
2. Confirmthatthepump(s)areoperatingandthat
theflowrateissufficienttomakethecontacton
theflowswitch.
3. Checkthewaterflowratebymeasuringthe
differentialpressureacrosstheevaporatorinlet
andoutletandcalculatingtheflowfromthe
evaporatorpressuredropdiagramprovidedin
thedocumentation.
4. Checkthecorrectfunctioningofanyflow
switchinstalled;closetheisolatingvalveonthe
evaporatoroutletandobservetheresultonthe
unitdisplaypanel;openthevalveandresetthe
flowtripalarm.
 
Afterhavingrigorouslyfollowedtheabovechecksitis
possibletostarttheunit:
1. Closetheelectricalpanel.
2. TurnthemainisolatortoON.
3. PressthekeyON for3secondstostartthe
unit.
PressingthekeyON displaysthewater
temperatureandtheoperatingmodeoftheunit.
Checktheoperatingsetpointparametersand
resetanyalarmspresent.Afterafewminutes
theunitwillstart.
 


- Thatthecompressorinputcurrentofthecompres-
sorsislessthanthatindicatedinthetableofelectri-
caldata.
- Thatinthreephasemodelsthecompressornoiseis
notabnormal,indicatingareverserotation.Inthis
casereverseoneofthephases.
- Thatthevoltagevaluesarewithinthedetermined
limitsandthatthephaseimbalance(threephase
power)islessthan3%.
- Presenceofanyrefrigerantleaks,inparcular
fromconneconstogauges,pressuretransducers
andpressostats.(Vibraonsduringtransportaon
mayhaveloosenedconnecons).
- Superheat
Comparethecompressorsuctiontemperaturewith
acontacttemperaturesensorreadingwiththe
temperatureofthelowpressuregauge(saturated
suctiontemperaturecorrespondingtotheevaporat-
ingpressure).Thedifferencebetweenthesetwo
temperaturesisthesuperheatvalue.Theoptimal
valuesarebetween4and8K.
- D i sc h arg e te m pe r a tu r e 
Ifthevaluesofsub-coolingandsuperheatare
normalthetemperaturemeasuredinthedischarge
linefromthecompressormustbe30/40Kabove
thecondensingtemperature.

:
- Themanualhighpressurepressostat,whichstops
thecompressorandgeneratesandalarmwhenthe
dischargepressureexceedsthepresetvalue.The
correctoperationischeckedbyclosingtherefriger-
antisolatingvalvetotheheatexchanger(incooling
mode)andkeepingacheckonthehighpressure
gauge,verifytheoperationcorrespondstotherated
value.Warning:intheeventthepressostatdoes
notoperateattheratedvalueimmediatelystop
thecompressorandinvestigatethecause.Resetis
manualbutcanonlybedonewhenthepressure
dropsbelowthedifferentialsetting.(Forthevalues
ofthetripanddifferentialsettingrefertothetech-
nicalmanual).
- Anti-freezeprotection
Theelectroniccontroloftheanti-freezeprotection
isfromthewatertemperaturesensorleavingthe
evaporatorpreventsfreezingofwaterwhenthe
temperatureistoolow.Theoperationoftheanti-
freezeprotectioncanbecheckedbyincreasingthe
setpointvalueuntilitisabovethetemperatureof
leavingwaterandcheckingthewatertemperature
withahighprecisionsensor.Confirmthattheunit
stopsandgeneratestherespondingalarm.Afterthis
checkresettheanti-freezesetpointtotheoriginal
value.
