AERMEC Variable Multi Flow ANL 580 User Manual

25
18.03. 5719210_03
ANL / 290-650
EN
 

1. Compressor
2. Plateheatexchanger
3. Thermostacexpansionvalve
4. Filterdrier
5. Solenoidvalve
6. Hotgasinjeconvalve
7. Safetyvalve
8. Unidireconalvalveonlyforversions
(02-04/P2-P4)
9. Liquidsightglass
10. Desuperheater(oponal)
11. Waterfilter
12. Pump(s)(oponal)
13.
Expansiontank(standardwithhydronicmodule)
14. Buffertank(optional)
15.
Flowswitch
16. Gauge
17. Airvent
18. Finnedcondensercoil
19. Fanassembly
20. Electricalpanel
21. MODU_CONTROLinterface

2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1
WARNING:

•ANL290-300-340(4fans).
•ANL400(6fans).

AERMEC Variable Multi Flow ANL 580 Specifications

General

Brand	AERMEC
Model	Variable Multi Flow ANL 580
Category	Chiller
Language	English
