SeveralparametersoftheMODUCONTROLboard
havetobeset,basedonthetypeofsystemtheunitis
installed.
Thesechangesofparametersaresummarisedinthe
tablebelowtopermittheinstallertomaketheap-
propriateselections.
 

ToaccesstheUSERsettingpressthekey and
confirmthepassword000pressingthekey .The
displaywillshowtheparametersoftheindex
asthreeidentifyingcharacters;theindexremainsdis-
playedforasecondandthenisreplacedbythevalue
oftheparameteritrelatesto.
Tomovetothefollowingparameterusethearrowkeys
.Tomodifyaparameterpressthekey ,modifythe
valueusingthearrowkeys andconfirmthemodifica-
tionpressingthekey .Toexitthemenupressthe
key .
 

Toenterandmodifythemenufollowthe
sameprocedureastheUSERmenuabove.

 ANSWER 


• Theunitisacoolingonlymodel • Gotoquestion2
• Radiantpanels • EnterinparameterStC(index3menuUSER)withthevalueof35°C
• Fancoilunitsorlowtemperature
radiators
• EnterinparameterStC(index3menuUSER)withthevalueof45°C(defaultvalue)
• Otherapplications • EnterinparameterStC(index3menuUSER)withthevalueof55°C


• Notinstalled • Gotoquestion3
• Installed • Enterinparameter(index9menuINSTALLER)withtheappropriatevalue:

• Seasonselectioncontrolledfromthechillercircuitboard
• ON/OFFcontrolfromthePR3

• SeasonselectioncontrolledfromthePR3
• ON/OFFcontrolfromthechillercircuitboard

• SeasonselectioncontrolledfromthePR3
• ON/OFFcontrolfromthePR3



• Notpresent • Gotoquestion5
• Present • EnterinparameterASA(menuINSTALLER)withthevalue(1)



• Notpresent • Gotoquestion5
• Present • EnterinparameterAAS(indexCmenuINSTALLER)withtheappropriatevalue(inseconds):
thisparametershowsthereversingtimeforthethreewaydivertingvalveinthecircuitforthe
productionofdomestichotwater


• Notpresent • Nofunction
• Present • Thisparameterenablesadigitalcontact(shownontheelectricalschematicwiththe
reference)ontowhichtoconnectanambientthermostatwithwhichtodisablethe
compressorsandelectricheaters.Enterinparameter,withthe
appropriatevalueselectingfrom:
 
 
 
• stopscompressorsandheatersiftheparametervalueissetto1
• stopscompressors,pumpandheatersiftheparametervalueissetto2
• pumpalarm(asintheprevioussoftwareversion),iftheparametervalueissetto3
WARNING
Formoreinformationrefertotheprovidedwiththeunitandavailableonthewebsite

