Subject to Export Control, see Cover Page for details. 2-55
A. Battery (cont)
REMOVE (cont)
3. Fully loosen five captive screws holding the
Battery Cover to the Test Set.
4. Remove the Battery Cover from the Test Set.
5. Disconnect the Battery Wire Harness.
6. Remove the Battery from the Test Set.
To Next Page
