A. Battery (cont)
INSTALL
1. Install the Battery in the Test Set.
2. Connect the Battery Wire Harness.
3. Install the Battery Cover on the Test Set and
tighten five captive screws (8 in/lbs.).
4. Install the two lower bumpers on the Test Set and
tighten the captive screws (on each side of the
bumpers) (8 in/lbs.).
FOLLOW-ON MAINTENANCE
None.
END OF TASK
