7.3. UDP Packets Accepted/Produced While GES Application is
Active
7.3.1. GES Status Command (Opcode: 0)
1
1
1
1
1
1
5
4
3
2
1
0
9
8
7
6
5
4
3
2
1
0
Length (3)
0
Opcode (0)
1
Spare (0)
2
GES
Summary
Status
1Hz
Update
Request
GES
Initiated
BIT Request
GES Traffic
Capture Mode
GES Operational
Status Mode
GES Operational
Performance Mode
Direction: To GES.
Word 2, Bit 0 – GES Summary Status 1Hz Update Request (0 – OFF, 1 – Request 1Hz updates)
Word 2, Bit 1 – GES Initiated BIT Status Request (0 – OFF, 1 – Request IBIT status)
Word 2, Bit 2 – GES Traffic Capture Mode (0 – nothing, 1 – Begin Traffic Capture Mode)
Word 2, Bit 3 – GES Operational Status Mode (0 – OFF, 1 – Operational Status Mode Active)
Word 2, Bit 4 – GES Operational Performance Mode (0 – OFF, 1 – Operational Performance
Mode Active)
When the GES receives a GES Status Command it will respond with a GES Summary Status
packet.
The GES also supports up to two requests for 1Hz GES Summary Status updates. The first two
requestors will receive GES Summary Status messages at approximately 1Hz intervals. If a
request for 1Hz updates comes from the same IP address, but from a different port it will replace
the previous 1Hz update request.
