Aeronix GES User Manual

GES – Users Manual
Page 22 of 33
7.3.6. GES Programming Command (Opcode 3)
1
1
1
1
1
1
5
4
3
2
1
0
9
8
7
6
5
4
3
2
1
0
Length (93)
0
Opcode (3)
1
Spare (0)
a
b
c
2
Spare (0)
Mirror Dest
3
Spare (0)
CPU
P11
P10
P9
P8
4
P7
P6
P5
P4
P3
P2
P1
P0
5
Primary IP Address (MSW)
6
Primary IP Address (LSW)
7
Primary Netmask (MSW)
8
Primary Netmask (LSW)
9
Secondary IP Address (MSW)
10
Secondary IP Address (LSW)
11
Secondary Netmask (MSW)
12
Secondary Netmask (LSW)
13
Direction: To GES.
Not yet supported.
This packet allows modification of the GES configuration stored in flash.
a – When set, this bit indicates that the Mirror Dest should be updated with the contents of this
packet.
b – When set, this bit indicates that the P0-P11 and CPU port mirroring details will be updated
with the contents of this packet.
c – When set, this bit indicates that the Network Parameters will be updated with the contents of
this packet (Primary IP & Netmask, as well as Secondary IP & Netmask).
Primary IP Address – The GES management processor’s primary IP address.
Primary Netmask – The GES management processor’s primary network mask.
Secondary IP Address – The GES management processor’s secondary IP address.
Secondary Netmask – The GES management processor’s secondary network mask.
Mirror dest – External port used as destination for data mirrored from other ports on this switch.
P0-P11, and CPU – Each port has two bits indicating the mirroring for the particular port.
00 – monitor no ingress or egress traffic.
01 – monitor ingress traffic only
10 – monitor egress traffic only
11 – monitor both ingress and egress traffic
