GES – Users Manual
Page 5 of 33
The primary purpose of this processor is to:
• Initialize the Ethernet Switch IC for GES default operation
• PBIT and CBIT
• Customer specific functions if required
3.4.4. Input Power
The connections shown in Table 3-1 with a Red background are Power Connections.
The input power requirements are as specified in MIL-STD-704A:
Aircraft, 28 VDC, Category B (curves 2 &3 of Fig. 9)
During normal operations the average power consumption with all 12 ports connected at
1 GB speed is 17 watts. Input current is internally limited to 2 amps.
